Perfect distribution, short residence time

Our crossheads have compact design and are very easy to handle and quick to assemble.

Description

Our Dual Crosshead ECH 140/175 DL has a manual centring system and conical shaped distributors.

The high performance and user friendliness of the head are achieved by combining smart design, close tolerances on all parts and unique distributor geometry. The conical distributors are designed in such a way that no special tools are required to install or remove them.

Included in the delivery are the vacuum connection (mainly for those working with tube tooling) and tool kit for assembly or disassembly of the crosshead.

Technical characteristics

Cable diameter, max. 175 mm
Entry diameter, max. 140 mm
Weight 1180 kg
No. of temperature controlled zones 7

Exact values depend on the assembly.

Options

  • Co-extrusion head for dual layer insulation / jacketing, or filling and jacketing
  • Two-extruder connection with or without a hydraulically operated bypass, at line height
  • Intermediate main extruder connection with a hydraulically operated bypass, and a manually or hydraulically operated head clamp
  • Main distributor optimized for PVC/LDPE, HDPE or HFFR
  • Crosshead trolley
